I Series Paver Mould Designs
PVC 9 IDOLE 3
| Specification | Details |
|---|---|
| Size | 230 mm x 200 mm / 9″ x 8" |
| Height | 60 mm |
| Area | 0.360 Sq.Ft/ 0.033 m² |
| Material | PVC |
| Mould Weight (Approx) | 2.000 Kg |
| Required Mould for 100 Sq.Ft. | 2.000 Kg |
| Required Mould for 1 M² | 30 Nos |
PVC 1 NEW IDOLE
| Specification | Details |
|---|---|
| Height | 60 mm |
| Area | 0.360 Sq.Ft. / 0.033 m² |
| Material | PVC |
| Mould Weight (Approx) | 1.950 Kg |
| Required Mould for 100 Sq.Ft. | 278 Nos |
| Required Mould for 1 M² | 30 Nos |
PVC 34 MINI IDOLE
| Specification | Details |
|---|---|
| Height | 55 mm |
| Area | 0.250 Sq.Ft./ 0.023 m² |
| Material | PVC |
| Mould Weight (Approx) | 1.350 Kg |
| Required Mould for 100 Sq.Ft. | 400 Nos |
| Required Mould for 1 M² | 43 Nos |
PVC 35 IDOLE
| Specification | Details |
|---|---|
| Height | 60 mm |
| Area | 0.360 Sq.Ft. / 0.033 m² |
| Material | PVC |
| Mould Weight (Approx) | 1.800 Kg |
| Required Mould for 100 Sq.Ft. | 278 Nos |
| Required Mould for 1 M² | 30 Nos |
PVC 36 IDOLE 4
| Specification | Details |
|---|---|
| Height | 60 mm |
| Area | 0.360 Sq.Ft./ 0.033 m² |
| Material | PVC |
| Mould Weight (Approx) | 1.950 Kg |
| Required Mould for 100 Sq.Ft. | 278 Nos |
| Required Mould for 1 M² | 30 Nos |
PVC 37 IDOLE 5
| Specification | Details |
|---|---|
| Height | 60 mm |
| Area | 0.310 Sq.Ft. / 0.029 m² |
| Material | PVC |
| Mould Weight (Approx) | 1.700 Kg |
| Required Mould for 100 Sq.Ft. | 323 Nos |
| Required Mould for 1 M² | 35 Nos |
PVC 172 IDOLE 6
| Specification | Details |
|---|---|
| Height | 75 mm |
| Area | 0.33 Sq.Ft. / 0.030 m² |
| Material | PVC |
| Mould Weight (Approx) | 2.050 Kg |
| Required Mould for 100 Sq.Ft. | 304 Nos |
| Required Mould for 1 M² | 34 Nos |
PVC 191 MINI IDOLE 40
| Specification | Details |
|---|---|
| Height | 75 mm |
| Area | 0.33 Sq.Ft. / 0.030 m² |
| Material | PVC |
| Mould Weight (Approx) | 2.050 Kg |
| Required Mould for 100 Sq.Ft. | 304 Nos |
| Required Mould for 1 M² | 34 Nos |
Start a Paver Block Manufacturing Factory.
We deliver end-to-end paver production solutions – combining advanced machinery, precision moulds, specialized chemicals, proven technology, and in-plant training. This integrated approach ensures our clients achieve consistent quality, operational efficiency, and long-term success.
